Setting Up the Printer

1-42

Note

9 Adjusting the Printing

After confirming that the nozzles are operating normally, print the printhead

alignment pattern and set each adjustment value. Before printing, make sure

A3 size or larger media is set.

Adjusting the Printhead Position

Execute “Print Pattern A” then do the settings for “A” ~ “K” to adjust the

printhead.

z You should use the most frequently used media to make the printhead adjustment.

z If you are using cut sheets, make sure at least three sheets of unused A3 paper (not

the blank sides of used paper) or larger are set. The printhead adjustment procedure

with cut sheets is slightly different, so just follow the instructions on the display.

If the printer is off, press the Power button to switch the printer on.

After a few seconds “Online” is displayed in the operation panel and the

Online lamp lights.

Press the Online button twice to display “MAIN MENU”.
